Wednesday, 25 April 2012

WEEK 13: Poster,Brochure & Flyers

WEEK 13


POSTER




BROCHURE






PLYERS


WEEK 12:FInishing The Project

WEEK 12




WEEK 11.Program For PIC 16F877A

WEEK 11












WEEK 10 :Program

WEEK 10


This some picture that my partner have program.
























WEEK 9 : Circuit 3 < Ctyron >

WEEK9


  This is the last circuit that use in this project.





KC Wirefree Bluetooth Module Starter Kit

Explaination:

       It is ready to interface with microcontroller without additional component.Supplementary USB to UART converter make SKKC-21 plug and play as Bluetooth dongle for functionality test.SKKC-21 mounted KC21.

   Features:

  • KC21 mounted
  • USB Plug AND Play UART function
  • 5V powered
  • 5V UART interface,ready for microcontroller interface
  • Default baud rate of 115.2 Kbps
  • Wireless Communication range < 20 meters
  • Compact yet east and reliable platfrom
  • As serial port replacement (wireless)



Tuesday, 24 April 2012

WEEK 8:Schematic Explaination

WEEK 8

In this week I will explain  how the  circuit function & operating.



         LCD DISPLAY SCHEMATIC DIAGRAM




               In this circuit diagram I will explain how the circuit function.The main component in this circuit is PIC16F877A the functions is to control all process and  it must be program it.The input will come  into analog signal and change to digital signal,how the process happen?The process must pass through 3 step  first sampling,quantars, and last one are  encoding.After that the output will come out to the LCD display.The power supply  that use in this circuit are 5v,we using adapter as our power supply.





TEMPERATURE SENSOR SCHEMATIC DIAGRAM






                 In this project contains 3 circuit board to make this project function.firstly is temperature sensor schematic as our input as we can see at the diagram have amplifier,resister 100k,temperature sensor and preset to control the sensitivity of the temperature sensor.To operating it  the temperature sensor will sent input to amplifier and  amplifier will amplifir  the signal  low to high signal to get the good signal or wave

WEEK 7: Constrct & Soldering

WEEK7

For week 7 I doing  construct & soldering after I finishing doing the pcb layout.


This some equitment that I used for soldering


solder
solder holder









first step we drill the foll on the pcb board that we do for last week






 second step we put the compement on the holl n but same on the schematic diagram,than we solder it
